RED has finally made the KOMODO available to order and published the full specifications of the camera.

Various colour versions for the camera have been around for quite a few months in a beta program but now the black production versions are finally available to order for $5,995 USD.

Technical Specifications

RED claims that the KOMODO has a dynamic range of 16+ stops, with a max 120fps at 2K or 40fps at 6K when recording RED RAW or ProRes.

SENSOR TYPEKOMODO™ 19.9 MP Super 35mm Global Shutter CMOS
EFFECTIVE PIXELS6144 x 3240
SENSOR SIZE27.03 mm x 14.26 mm (Diagonal: 30.56mm)
DYNAMIC RANGE16+ Stops
MOUNT TYPERF mount
Accepts Canon RF mount-based lens adaptors for diverse lens choices
Supports Canon EF with full electronic communication via compatible Canon RF mount adapters, and supports mechanically operated RF lenses (electronic control of Canon RF lenses not supported at this time) [1]
MAX DATA RATESUp to 280 MB/s using RED Pro CFast or other qualified CFast 2.0 media cards [1]
REDCODE® RAW MAX FRAME RATES40 fps at 6K 17:9 (6144 x 3240)
48 fps at 5K 17:9 (5120 x 2700)
60 fps at 4K 17:9 (4096 x 2160)
120 fps at 2K 17:9 (2048 x 1080)
PLAYBACK FRAME RATES (PROJECT TIME BASE)23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps, all resolutions
BEST AVAILABLE REDCODE® SETTINGSREDCODE HQ, MQ and LQ at 6K 17:9 (6144 x 3240) up to 40 fps
REDCODE HQ, MQ and LQ at 4K 17:9 (4096 x 2160) up to 60 fps
REDCODE HQ, MQ and LQ at 2K 17:9 (2048 x 1080) up to 120 fps
REDCODE® RAW
ACQUISITION FORMATS2
6K 17:9 (6144 x 3240), 2.4:1 and 16:9
5K 17:9 (5120 x 2700)
4K 17:9 (4096 x 2160)
2K 17:9 (2048 x 1080)
APPLE PRORES4K (4096 × 2160) at ProRes 422 HQ and ProRes 422 up to 60 fps
2K (2048 × 1080) at ProRes 422 HQ and ProRes 422 up to 120 fps
CONSTRUCTIONAluminum Alloy
WEIGHT2.10 lbs (without body cap and Cfast card)
BATTERY TYPETwo slots for BP-9XX series batteries
DC POWER INPUT+7 to +17 V DC via the integrated 2-pin DC-IN port
Operating Temperature0°C to 40°C (32°F to 104°F)
STORAGE TEMPERATURE–20°C to 50°C (–4°F to 122°F)
STORAGE RELATIVE HUMIDITY0% to 85% non-condensing
COLOR MANAGEMENTImage Processing Pipeline 2 (IPP2)
Supports 33×33×33 3D LUTs
Supports import of CDLs
AUDIOIntegrated dual channel digital mono microphones, uncompressed, 24-bit 48 kHz
Additional dual channel via integrated 3.5mm audio jack, uncompressed, 24-bit 48 kHz
REMOTE CONTROLWiFi for camera control via interchangeable antenna with SMA connection
Genlock, Timecode-in, GPIO and Ctrl (RS232) via the integrated 9-pin EXT Port
Wired control via KOMODO Link Adaptor, using USB-C or Gigabit Ethernet (compatible USB-C to Ethernet adapter1 required) allowing camera control and live MJPEG preview video feed
MONITOR OUTPUTSIntegrated 12G-SDI with 6G-SDI, 3G-SDI and 1.5G-SDI modes
12G-SDI: Up to 4096 x 2160 4:2:2 for 60p
6G-SDI: Up to 4096 x 2160 4:2:2 for 30p
3G-SDI: Up to 2048 x 1080 4:2:2 for 60p
1.5G-SDI: Up to 2048 x 1080 4:2:2 for 30p, 24p
SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio
MONITOR OPTIONSIntegrated 2.9″ 1440×1440 touchscreen LCD with preview and camera control
Wireless live preview video feed via 2.4Ghz/5Ghz WiFi for framing
RED CONTROLAccess full camera controls and live preview from iOS or Android devices.
Available from the Apple App Store and Google Play Store (coming soon). RED Control works wirelessly or wired via the KOMODO Link Adaptor (sold separately).

Accessories

RED has also officially released the accompanying accessories for the KOMODO with the Outrigger Handle, Expander Module & Wing Grip.
